Beige Silicone Pad

Beige silicone pad made from silicone rubber and fiberglass, with heat and pressure resistance, cushioning, and flatness. Highly reusable, electrically insulating, thermally conductive, voltage resistant, and easy to install, with a fiberglass carrier.

Brand

Lixing Compound Materials

Origin

Zhuhai, Guangdong, China

Supply

Factory direct; custom sizes and cutting available

Samples

Samples available on request

Product Details

Beige Silicone Pad

Adhesive backing available on request; supplied in rolls or die-cut sheets.

Product Details

Name	White Silicone Pad
Material	Silicone + fiberglass
Size	Length: 10M (Or as a sheet) Thickness: 1.6mm (customizable) Width: 600mm (customizable)
Specific Gravity	1.3g/cm3±0.2 g/cm3
Service Life	Depends on the environment and operating conditions Recommended storage temperature: 15-25 degrees Recommended storage humidity: <65% RH 6 months
color	WHITE
Thickness of glass fiber	0.2±0.02mm
Hardness	60HA±5HA
Elongation	＞380%±10%
Peel strength	＞80kgf/c ㎡
Operating temperature	160° ~250°
Shelf Life	6 months
Function	Install on the hot press. Silicone cushions the workpiece against the heated platen during pressing. Silicone distributes heat more evenly across the surface and helps prevent burns.
Notice	The heated platen must be flat and free of scratches. Install the material flush against the platen surface. Do not fold sharply, as this may cause deformation. The recommended temperature is 160-250°.
